6.
1Warningsandcautions
Important:
Beforeproceeding,ensurethatyouhavereadandunderstoodthe
warningsandcautionsprovidedinthefollowingsectionofthisdocument:
p .9—Importantinformation
Warning:Potentialignitionsource
ThisproductisNO
Tapprovedforuseinhazardous/flammable
atmospheres.DoNOTinstallinahazardous/flammable
atmosphere(suchasinanengineroomornearfueltanks).
6.2Generallocationrequirements
Whenselectingalocationforyourproductitisimportanttoconsidera
numberoffactors.
K eyfactorswhichcanaffectproductperformanceare:
•Ventilation—T oensureadequateairflow:
–Ensurethatproductismountedinacompartmentofsuitablesize.
–Ensurethatventilationholesarenotobstructed.Allowadequate
separationofallequipment.
Anyspecificrequirementsforeachsystemcomponentareprovidedlater
inthischapter.
•Mountingsurface—Ensureproductisadequatelysupportedonasecure
surface.Donotmountunitsorcutholesinplaceswhichmaydamage
thestructureofthevessel.
•Cabling—Ensuretheproductismountedinalocationwhichallowsproper
routing,supportandconnectionofcables:
–Minimumbendradiusof100mm(3.94in)unlessotherwisestated.
–Usecableclipstopreventstressonconnectors.
–Ifyourinstallationrequiresmultipleferritestobeaddedtoacablethen
additionalcableclipsshouldbeusedtoensuretheextraweightofthe
cableissupported.
•Wateringress—Theproductissuitableformountingbothaboveand
belowdecks.Althoughtheunitiswaterproof,itisgoodpracticetolocate
itinaprotectedareaawayfromprolongedanddirectexposuretorain
andsaltspray.
•Electricalinterference—Selectalocationthatisfarenoughawayfrom
devicesthatmaycauseinterference,suchasmotors,generatorsandradio
transmitters/receivers.
•Powersupply—Selectalocationthatisascloseaspossibletothe
vessel’sDCpowersource.Thiswillhelptokeepcablerunstoaminimum.
Caution:Productweight
•Refertothetechnicalspecificationforyourproductto
ensuretheintendedmountingsurfaceissuitabletobear
itsweight.
•2peoplemayberequiredforinstallationoflarger/heavier
products.
Rearaccessrequirements
Accesstotherearofthedisplayandmountingsurfaceisrequiredtosurface
andflushmountthedisplay.
Ensurethereissufficientaccessandspacebehindthemountingsurfaceto
attachandtightenthefixingsandalsotoconnectthecables.
6.3Axiom®2XL24abovedecksinstallation
requirements
Note:
TheinstallationrequirementsbelowonlyapplytotheAxiom®2XL24
whenbeinginstalledinanabovedecksenvironment.
L ocationrequirements
25
