12.
1Touchcontrolinputconnection
Y oucanviewandcontrolthedisplayfromaconnectedhighdefinition
touchscreenmonitorbyconnectingthemonitortotheHDMIOUTand
TOUCHCONTROLINconnectorslocatedontherearofthedisplayusingthe
.HDMIcableaccessory(partnumber:A80219)andtheUSBAtoUSBBcable
accessory(partnumber:A80578).Thedisplayscreencanthenbeviewedby
switchingthemonitor’ssourcetotheHDMIconnectionyouconnectedthe
cabletoandcontrolledbyusingthemonitor’stouchscreen.
ThestandardHDMIconnectorandstandardUSBconnectorontheaccessory
cablesareconnectedtothemonitorandtheotherendofthecablesare
connectedHDMIOUTandTOUCHCONTROLINconnectors.
Note:
Ensurethatthelockingcollarsareusedtosecuretheconnectionstothe
display .
1.Display .
2.Display’sTOUCHCONTROLINconnector.
3.Display’sHDMIOUTconnector.
4.HDMIcable(partnumber:A80219)—Notsupplied.
5.USBAtoUSBBcable(partnumber:A80578)—Notsupplied.
6.HDtouchscreendisplay.
12.2Touchoutconnection
Y oucanviewandcontrolapersonalcomputerorsimilardevicefromthe
displaybyconnectingthedevicetotheHDMIINandTOUCHCONTROL
OUTconnectorslocatedontherearofthedisplayusingthe.HDMIcable
accessory(partnumber:A80219)andtheUSBBtoUSBAcableaccessory
(partnumber:A80579).Thedevicecanthenbeviewedandcontrolledfrom
thedisplayusingVideoappandthedisplay’stouchscreen.
ThestandardHDMIconnectorandstandardUSBconnectorontheaccessory
cablesareconnectedtothemonitorandtheotherendofthecablesare
connectedHDMIINandTOUCHCONTROLOUTconnectors.
Note:
Ensurethatthelockingcollarsareusedtosecuretheconnectionstothe
display.
1.Display.
2.Personalcomputer.
3.Display’sTOUCHCONTROLOUTconnector.
54
