Raymarine AXIOM 2 XL User Manual

18.
1Powerspecification
Specification
Nominalsupplyvoltage:
12V/24Vdc
Operatingvoltagerange:8Vdcto32Vdc
Current(Maximum):
8.56A
Off-current(Maximum@12
Vdc)
•P
oE—2,135mA(25.62Watts)
•NoPoE—352mA(4.32Watts)
Off-current(Maximum@24V
dc)
•PoE—1,161mA(27.86Watts)
•NoPoE—352mA(5.54Watts)
P oEoperatingvoltagerange:
9.5Vdcto32Vdc
Fuserequirements:
•Inlinefuse=15Amp,or
•Thermalbreaker=15Amp
P owerconsumption:
(Maximum@12Vdc)
76.56Watts
Powerconsumption:
(Maximum@24Vdc)
71.35Watts
18.2Environmentalspecification
Specification
Operatingtemperature
range:
-25°C(-13°F)to+55°C(131°F)
S toragetemperaturerange:
-30°C(–22°F)to+70°C(158°F)
Humidity:
upto93%@40°C(104°F)
W ateringressprotection:
IPx6andIPx7
Installationlocation:
•Abovedecks
•Belowdecks
18.3L
CDspecification
Specification
Size(diagonal):
15.6”
T
ype:
IPS(In-PlaneSwitching)
Colordepth:24bit
R
esolution:
1920x1080FHD
Ratio:
16:9
Illumination:
1300nits/1300cd/m
2
Viewingangle:
Top88°/Bottom88°/Left88°/Right88°
Numberofsimultaneous
touches:
2
18.4Physicalspecification
Specification
Gross(boxed)product
weight:
8.32kg(18.34lbs)
Net(unboxed)product
weight:
5.84kg(12.88lbs)
Dimensions:
Height:248.22mm(9.77in),Width,394.9
mm(15.55in),Depth(includingcables):
174.95mm(6.89in).
Internalstorage:
64GBsolidstate.
Externalstorage:Remotecardreaderrequired.
Axiom2XL16technicalspecification
77
