3.
7Productdimensions
1.Sideviewofscanner .
2.Rearviewofscanner.
3.Undersideviewofscanner.
DimensionMeasurementDescription
A
116.0mm(4.57in.)
Distancefromcenterlineof
scannertofrontofmounting
base .
B
355.0mm(13.98in.)
Distancefromrearofmounting
basetofrontofmountingbase .
C
209 .5mm(8.25in.)
Heightofradarscanner.
D
319 .5mm(12.58in.)Mountingbasewidth(rearof
unit).
E
541.0mm(21.30in.)
Widthofscanner
.
F
116.5mm(4.59in.)
Distancefromcenterlinetorear
mountinghole .
G
233.0mm(9 .17in.)
Distancebetweenmounting
holes.
Planningtheinstallation
27
