4.2Connectionsoverview
Usethefollowinginformationtohelpyouidentifytheconnectionsonyourproduct.
ConnectorConnectsto:Suitablecables
R
ayNetnetworkordevice.Not
requiredifconnectingusing
Wi-Fi.
RefertotheChapter10Spares
andaccessoriessection.
12V/24Vpowersupply.
Suppliedwithyourproduct.
Thepoweranddataconnectionsarelocatedontheundersideofthescannerunit,asshowninthe
followingillustration.
