Cablerouting—polemount
Thereare2typicalcableroutingscenariosforpolemountinstallations.
•Usingseparatepoweranddatacables.
•Usingane
xistingcombinedpower/datacablefromanolderRaymarineDigitalRadarscanner.In
thisscenario,the
A
80308Y-adapteraccessoryisrequired(notsuppliedwiththescanner).
Usingseparatepoweranddatacables
Note:Theroutingoptionsdescribedandillustratedinthissectionassumethataphysicaldata
connectionisusedbetweenyourR
adarscannerandmultifunctiondisplay(MFD).However,ifthe
scannerisconnectedtoyourMFDviaWi-Fi,aphysicalRayNetconnectionisnotrequired.
Thefollowingdrawingillustratesthecableroutingforascannermountedonaplatform,using
separatecablesforthepoweranddataconnection.
1.R ayNetdataconnection.
2.12V/24Vpowerconnection.
Note:
•AseparatepowercableissuppliedwithallQuantum
™
R adarvariants.
•NotallQuantum
™
radarvariantsaresuppliedwithaRayNetcable.RefertotheChapter2
Documentandproductinformationsectionformoreinformation.
•Refertothe10.4RayNettoRayNetcablesandconnectorssectionforinformationonsuitable
accessoryRayNetcables.
46
