9
LR
LR
RL
L
B
R
SURROUND
SPEAKERS
FRONT
SPEAKERS
AC OUTLET
PCM /
2
/ DTS
DIGITAL IN
TO
MONTOR
TV
VCR /
DVR
CONTROL
IN
AUX
CD
IN
IN IN OUT
OUT
CD - R
/ TAPE
/ MD
SURROUND
CENTER
SUB
WOOFER
SUB
WOOFER
PREOUT
IN
IN
IN
IN
IN
TV /
SAT
DVD
/ LD
CENTER
PREOUT
COAX OPT1 OPT2
O
U
T
R
E
C
P
L
A
Y
OUT
FM
UNBAL
75Ω
AM LOOP
ANTENNA
FM
ANTENNA
DVD 5.1 CH
INPUT
LR
CENTER
SPEAKER
FRONT
SPEAKERS
OUTPUT
VIDEO
L
R
OUTPUT
INPUT
VIDEO
L
R
VIDEO
L
R
OUTPUT
VIDEO
L
R
INPUT
VIDEO
DVD player
(or LD player)
Video deck
TV tuner
(or Satellite tuner)
TV
(monitor)
Audio/Video cords
Use audio/video cords (not supplied) to connect the video components and a video cord to
connect the monitor TV.
Connect red plugs to R (right), white plugs to L (left), and
the yellow plugs to VIDEO.
Be sure to insert completely.
L
R
VIDEO
CONNECTING VIDEO COMPONENTS
Connect your video components to the jacks as shown below. Regarding digital video components (like a
DVD player), you must use the analog connections pictured on this page for the video signal but in order
to use Dolby Digital you should hook up their audio to a digital input (see the next page). It is also a good
idea to hook up your digital components with analog audio connections as well (see the previous page).
To cover all possible laser discs a DVD/LD player or LD player requires an analog connection (as shown
here) and two digital connections (see the next page).
When connecting your equipment always make sure the power is turned off and the power cord is
disconnected from the wall outlet.
