3
1. Getting Started
Connecting the Machine
Confirm that the shape and the position of the connector are as shown in the il-
lustration.
1. 10BASE-T/100BASE-TX (option)
2. Parallel Port
Requirements
Requirements
Before using this machine, confirm that all the environmental and electrical re-
quirements have been met. Connect the machine to the host computer using the
parallel port, optional Network Interface Board Type 450-E, or both.
Confirm that all the cables, connectors, and electrical outlets necessary to attach
the machine to the host computer or network are present.
Important
❒ The interface cable is not supplied in the box. It is your responsibility to pro-
vide the interface cable appropriate for the computer that you are using.
Reference
For more information about using the parallel port, see p.6 “Connecting the
Machine to the Host Using the Parallel Interface Cable”.
For more information about using a network, see p.4 “Network cable require-
ments”.
