Ricoh Aficio GX7000 User Manual

Multiple sheets of paper are fed at one time.
Load the paper again. Remove the paper from the paper tray, fan it well, and tap it on a flat surface such
as a desk to even the edges. Check the position of the paper guides of the paper tray, and then load the
paper again. See p.90 "Paper Handling Precautions", p.43 "Loading Paper".
Though a paper jam is cleared, paper does not feed.
When a paper jam occurs, clear the paper jam, and then press the [Form Feed / Head-cleaning] key. See
p.178 "Using the [Form Feed / Head-cleaning] Key to Remove Jammed Paper".
The bypass tray cannot be selected.
The printer driver cannot detect the bypass tray.
If the bypass tray cannot be detected, open the printer properties dialog box. In [Bypass Tray Unit] on the
[Accessories] tab in the printer properties dialog box, check whether the bypass tray is shown as being
attached.
Paper is jammed in the duplex unit.
The duplex unit is properly locked into position. but not locked.
Attach the duplex unit properly. For details, see p.232 "Duplex Unit Not Detected".
• If an error is displayed on the Status monitor, follow the instructions to solve the problem. See
p.212 "Status Monitor Errors".
Paper Is Not Fed or Delivered Normally
177
6

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
