Ricoh Aficio GX7000 User Manual

• p.176 "Paper Is Not Fed or Delivered Normally"
•
p.28 "Detaching and Reattaching the Multi Bypass Tray"
• p.26 "Detaching and Reattaching the Duplex Unit"
Removing Paper Jammed in the Duplex Unit (optional)
Follow the procedure below to remove paper jammed in the duplex unit.
• If the multi bypass tray is attached to the printer, switch the printer off and detach the multi bypass
tray.
You can feed the jammed paper to tray 1 output ramp by opening the left cover and turning the paper
feed wheel.
BAJ309S
If turning the paper wheel does not remove the jammed paper, use the following procedure to remove it:
1. Press the duplex unit cover button at the centre of the bypass tray, and then open the duplex
unit cover.
BAJ031S
Paper Jam
193
6

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
