Ricoh Aficio GX7000 User Manual

To apply this function: under [Maintenance], set [Key Repeat] to [On].
9.
[#Enter] key
Press this key to execute menu items selected on the display.
10. [Escape] key
Press this key to return to the previous condition on the display.
11. [Power] key
• Press to turn the power on and off.
• To turn the power on, press and hold down the [Power] key for one second until it lights.
• After the power is turned on, the [Power] key will flash until the printer is ready for printing, at which point
the key will stop flashing and remain lit.
• When the power is turned off, the key will blink slowly until the printer has completely shut down at which
point the key will be dark.
•
means “standby”. To avoid any power consumption, disconnect the power plug from the wall outlet.
12.
Data In indicator
Blinks when the printer is receiving data from a computer. The Data In indicator is lit if there is data to be printed.
• For details about the Key Repeat, see p.133 "Performing Maintenance using the Control Panel
(Maintenance Menu)".
Guide to Components
21
1

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
