Ricoh Aficio GX7000 User Manual

Paper capacity
Tray 1: 250 sheets
Maximum paper capacity
600 sheets (with the optional tray installed)
Tray 1 output ramp capacity
150 sheets
The capacity may be less depending on the images printed.
Power supply
: 50/60 Hz, 0.55 A or more (when fully equipped)
: 50/60 Hz, 1.1 A or more (when fully equipped)
Power consumption
Average power consumption while printing:
35 W or less (not including options)
Energy Saver mode:
less than 5 W
To avoid any power consumption, disconnect the power plug from the wall outlet.
(Unplug the power plug only after making sure the [Power] key indicator is off.)
Operating environment
Temperature: 10 to 32°C (50 to 89.6°F))
Humidity: 15-80% RH (maximum wet-bulb temperature: 25°C (77°F))
Printing may stop to protect the printer for conditions outside those described above.
Storage environment
Temperature: 1 to 40°C (33.8 to 104°F)
Humidity: 5-80% RH
External dimensions
(W × D × H) 545 × 491 × 265 mm (21.5 × 19.3 × 10.4 inches)
(W × D × H) 545 × 660 × 366 mm (21.5 × 26.0 × 14.4 inches) (when fully equipped)
Weight
Approximately 19.2 kg (42.4 lb.) (printer body with consumables)
Approximately 28 kg (61.8 lb.) (when fully equipped)
Specifications
251
7

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
