Ricoh Aficio GX7000 User Manual

3. Using a coin, turn the network interface board cover screw counterclockwise, and then
remove the cover.
BAJ040S
4. Remove the spacer in the network interface board cover.
AKR130S
The removed spacer will not be used again.
5. Align the network interface board notch with the triangular mark on the printer, and then
push in the network interface board by pressing the part marked “PUSH”.
BAJ083S
6. Reattach
the network interface board cover to the printer, and then secure it with the screw
provided.
• Be sure to push the network interface board fully into the printer.
2. Preparing for Printing
36
2

Ricoh Aficio GX7000 Specifications

Power

power source	100 – 120V, 50/60Hz
power consumption	35W or less
energy saver mode	5W or less

Printing Specifications

resolution	True 1200 x 1200 dpi, 600 x 600 dpi, 600 x 300 dpi (Maximum 3600 x 1200 dpi equivalent)
printing speed	29 pages-per-minute in B&W and full-color
first print speed	B&W: 6.5 seconds or less, Color: 9 seconds or less

Paper Handling

paper capacity	250-Sheet Standard Paper Tray, 100-Sheet Multi-Bypass Tray, 250-Sheet Paper Feed Unit
maximum paper capacity	600 sheets
output capacity	100 sheets (face up)

Weight and Dimensions

dimensions	21.4" x 21.9" x 10.4" / 545 x 558 x 269 mm
weight	42.1 lbs. / 19.1 kg
