Page #130 background imageLoading...
Page #130 background image
This function is displayed only on Type 1 models that have no hard disk installed.
For details about the optional SDRAM module, see Hardware Guide.
Auto E-mail Notify
Specify whether or not to send an error message to a preset e-mail address when an error occurs in
the printer.
After changing the setting, turn off the power of the printer briefly, and then turn it on again.
Default: [On]
On
Off
For information, see Web Image Monitor Help.
Changing the System Menu
Follow the procedure below to change the settings for Energy Saver Timer.
1. Press the [Menu] key.
BYK087
The menu screen appears.
2. Press the [ ] or [ ] key to select [System], and then press the [OK] key.
3. Press the [ ] or [ ] key to select [Auto Off], and then press the [OK] key.
4. Press the [ ] or [ ] key to select [Auto Off Timer], and then enter the [OK] key.
5. Press the [ ] or [ ] key to select the lead time needed to switch to auto off mode.
6. Press the [OK] key.
Wait for one second. The Auto Off appears.
5. Making Printer Settings Using the Control Panel
128
5

Table of Contents

Other manuals for Ricoh Aficio SP C430DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio SP C430DN and is the answer not in the manual?

Ricoh Aficio SP C430DN Specifications

Ricoh Aficio SP C430DN

Power IconPower
power requirements120 – 127V, 60Hz
power consumption (operating)825W or less
power consumption (energy saver)110W
power consumption (sleep)6W
Print Speed and Resolution IconPrint Speed and Resolution
print speed (full-color & monochrome)37 ppm
resolution1200 x 1200 dpi
Paper Handling IconPaper Handling
standard paper supply550-Sheet Tray + 100-Sheet Bypass Tray
maximum paper capacity2, 300 sheets
output capacity500 sheets, face down
Weight and Dimensions IconWeight and Dimensions
dimensions17.48” x 25.91” x 19.29” (444 x 658 x 490 mm)
weight126 lb. (57 kg)

Ricoh Aficio SP C431DN

Power IconPower
power requirements120 – 127V, 60Hz
power consumption (operating)894W or less
power consumption (energy saver)110W
power consumption (sleep)6W
Print Speed and Resolution IconPrint Speed and Resolution
print speed (full-color & monochrome)42 ppm
resolution1200 x 1200 dpi
Paper Handling IconPaper Handling
standard paper supply550-Sheet Tray + 100-Sheet Bypass Tray
maximum paper capacity2, 300 sheets
output capacity500 sheets, face down
Weight and Dimensions IconWeight and Dimensions
dimensions17.48” x 25.91” x 19.29” (444 x 658 x 490 mm)
weight126 lb. (57 kg)
