Ricoh Aficio SP C430DN User Manual

PDF Direct Print Properties
BRP007S
1
2
3
4
5
6
7
8
9
10
15
11
12
13
14
1. Setting name:
Displays the plug-in configuration name (up to 63 single byte characters)
2. Change Icon...
Changes the icon displayed on the tool bar.
3. Printer:
Displays printer's IP address or hostname.
4. Duplex
Prints on both sides of sheets.
5. Layout
Prints multiple pages on a single sheet.
6. Punch (not supported for this printer)
Punches holes in printed sheets.
7. Staple (not supported for this printer)
Staples together printed sheets.
8. Display this dialog box before printing
Appears in PDF direct printing mode if this check box is selected.
9. Orientation:
Specify the original's orientation.
10. Number of copies
Specify the number of copies to print.
11. Collate
Sorts printed sheets.
2. Printing Documents
52
2

Ricoh Aficio SP C430DN Specifications
