Ricoh IM C6500 User Manual

Thick Paper Orientation and Recommended
Status
When loading thick paper of 127.5–300.0 g/m
2
(47.0 lb. Cover–165.0 lb. Index), follow the
recommendations below to prevent misfeeds and loss of image quality.
Paper Orientation
Thick paper has a paper direction according to its grain. Set the paper direction according to the
grain, as shown in the following diagram:
Direction of paper
grain
Tray 1 or LCT Trays 2–3 Bypass tray or wide LCT
Not recommended
Paper Storage
• Temperature: 20–25°C (68–77°F)
• Humidity: 30–65%.
Do not use together paper that has been stored in different environments.
Minimum Number of Sheets
• 20 sheets or more (paper trays of the machine/optional lower paper trays unit used)
After loading paper, position the side fences flush against the paper stack.
• When printing on thick, smooth paper, be sure to fan the paper thoroughly before loading. If you
do not fan thick paper, jams and misfeeds can occur. If paper continues to become jammed or
feed in together even after they are fanned, load them one by one from the bypass tray.
• Proper performance and quality may not be achieved under the recommended conditions
depending on the paper.
• The printed sheet may curl. If the printed sheet curls, correct it.
Thick Paper Orientation and Recommended Status
229

Ricoh IM C6500 Specifications

General

Category	All in One Printer
Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
ADF Capacity	220 sheets
Duplex Printing	Yes
Monthly Duty Cycle	300, 000 pages
Hard Drive	320 GB
Control Panel	10.1" Color Touchscreen
Print Speed	65 ppm
Copy Speed	65 cpm
Scan Speed	240 ipm (duplex)
Scan Resolution	600 dpi
Fax Speed	33.6 kbps
Fax Resolution	200 x 200 dpi
Supported Paper Sizes	A3, A4, A5, A6, B4, B5, B6
Maximum Paper Size	A3
Connectivity	Ethernet, USB
Interface	Ethernet, USB
Memory	4 GB RAM
