List of Specifications for Internal Options
• We have licenses from the authors to use their software including open sources. Refer to the files in
the Licenses folder included in the supplied CD-ROM for statements requested from the authors.
Specifications for Facsimile
This function may not be used depending on the telephone line or area status.
• To connect the machine to the network, use a LAN cable supporting 1000BASE-T, 100BASE-TX,
and 10BASE-T. The length of the usable cable is up to 100 m.
Fax Transmissions and Reception
Item Specifications
Standard G3
Resolution • Standard: 8 × 3.85 lines/mm, 200 × 100 dpi (Standard
character), 8 × 7.7 lines/mm, 200 × 200 dpi (Detail character)
• Optional: 8 × 15.4 lines/mm, 16 × 15.4 lines/mm, 400 × 400
dpi (Super Fine character)
*1
Transmission time 3 seconds at 28,800 bps, Standard resolution (JBIG transmission: 2
seconds)
Data compression method MH, MR, MMR, JBIG
*2
Maximum original size Standard: A3 or 11 × 17
Custom (w × h): 297 × 1,200 mm (11.7 × 47.3 inches)
Maximum scanning size 297 × 1,200 mm (11.7 × 47.3 inches)
Print process Laser beam scanning and electro-photographic printing
Transmission speed 33,600 / 31,200 / 28,800 / 26,400 / 24,000 / 21,600 /
19,200 / 16,800 / 14,400 / 12,000 / 9,600 / 7,200 / 4,800 /
2,400 bps (auto shift down system)
*1
For Super Fine transmission, an expansion memory (optional) is required.
*2
JBIG transmission cannot be performed if the JBIG reception and ECM functions are not available on the
destination fax. The ECM function is valid for communication over the G3 line.
List of Specifications for Internal Options
357
