Rigol DS1000 Series User Manual

RIGOL
© 2006 RIGOL Technologies, Inc.
User‟s Guide for DS1000 Series
5-1
Chapter5 Specifications
All specifications apply to the DS1000 Series Oscilloscopes unless noted otherwise. To
meet these specifications two conditions must first be met:
 The instrument must have been operating continuously for thirty minutes within
the specified operating temperature.
 Must perform the Self Cal operation, accessible through the Utility menu, if the
operating temperature changes by more than 5°C.
All specifications are guaranteed unless noted “typical”.
Specifications
Acquisition
Sampling Modes
Real-Time
Equivalent
Sampling Rate
400Sa/s(single channel)*, 200MSa/s**
200MSa/s(double channels) ,200MSa/s**
25GSa/s***
Averages
N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Inputs
Input Coupling
DC, AC, GND
Input Impedance
1MΩ± 2%, in parallel with 15pF± 3pF
Input Impedance of LA is 100kΩ**
Probe Attenuation Factors
1X, 5X, 10X, 50X,100X, 500X, 1000X
Maximum Input Voltage
400V (DC＋AC Peak, 1MΩ input impedance)
40V (DC+AC Peak)**
Time delay between channel
(typical)
500ps
