User‟s Guide for DS1000 Series
5-4
Trigger
Trigger Sensitivity
0.1div-1.0div (adjustable)
Trigger Level Range
Internal
± 6 divisions from center of screen
EXT
± 1.2V
EXT/5
± 6V
Trigger Level Accuracy
(typical) applicable for
the signal of rising and
falling time ≥20ns
Internal
± (0.3div× V/div)(± 4 divisions from center of
screen)
EXT
± (6% of setting + 40 mV)
EXT/5
± (6% of setting + 200 mV)
Trigger Offset
Normal mode: pre-trigger (262144/ sampling rate),
delayed trigger 1s
Slow Scan mode: pre-trigger 6div, delayed trigger 6div
Trigger Holdoff range
100ns-1.5s
HF reject
120kHz± 20％
LF reject
8kHz± 20％
Set Level to 50%
(Typical)
Input signal frequency ≥50Hz
Edge Trigger
Edge trigger slope
Rising, Falling, Rising + Falling
Pulse Trigger
Trigger condition
(＞, ＜, =) Positive pulse, (＞, ＜, =) negative pulse
Pulse Width range
20ns – 10s
Video Trigger
Video standard &
line frequency
Support standard NTSC, PAL and SECAM broadcast systems.
Line number range: 1-525 (NTSC) and 1-625 (PAL/SECAM)
Slope Trigger
Trigger condition
(＞, ＜, =) Positive slope, (＞, ＜, =) negative slope
Time setting
20ns – 10s
Alternate Trigger
Trigger on CH1
Edge, Pulse, Video, Slope
Trigger on CH2
Edge, Pulse, Video, Slope
Pattern Trigger **
Trigger mode
D0 – D15 select H, L, X, ,
Duration Trigger **
Trigger Type
D0 – D15 select H, L, X
Qualifier
＞, ＜, =
Time setup
20ns – 10s
