 :MATH<n>:FILTer:TYPE
 :MATH<n>:FILTer:W1
 :MATH<n>:FILTer:W2
 :MATH<n>:SENSitivity
 :MATH<n>:DISTance
 :MATH<n>:THReshold1
 :MATH<n>:THReshold2
:MATH<n>:DISPlay
Syntax
:MATH<n>:DISPlay <bool>
:MATH<n>:DISPlay?
Description
Enables or disables the math operation function; or queries the status of the math
operation function.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<bool>
Bool
{{1|ON}|{0|OFF}}
0|OFF
Return
Format
The query returns 1 or 0.
Example
:MATH1:DISPlay ON /*Enables the operation function of Math1.*/
:MATH1:DISPlay? /*The query returns 1.*/
:MATH<n>:OPERator
Syntax
:MATH<n>:OPERator <opt>
:MATH<n>:OPERator?
Description
Sets or queries the operator of math operation.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<opt>
Discrete
{ADD|SUBTract|MULTiply|DIVision|AND|OR|X
OR|NOT|FFT|INTG|DIFF|SQRT|LOG|LN|EXP|
ABS|LPASs|HPASs|BPASs|BSTop|AXB}
ADD
Return
Format
The query returns ADD, SUBT, MULT, DIV, AND, OR, XOR, NOT, FFT, INTG, DIFF, SQRT,
LOG, LN, EXP, ABS, LPAS, HPAS, BPAS, BST, or AXB.
Example
:MATH1:OPERator INTG /*Sets the math operator of Math1 to Integrate.*/
:MATH1:OPERator? /*The query returns INTG.*/
