Rigol DS7024 User Programming Manual

RIGOL Chapter 2 Command System
2-96 MSO7000/DS7000 Programming Guide
Example
:MATH1:LSOUrce1 D3 /*Sets Source A of the logic operation to D3.*/
:MATH1:LSOUrce1? /*The query returns D3.*/
:MATH<n>:LSOUrce2
Syntax
:MATH<n>:LSOUrce2 <src>
:MATH<n>:LSOUrce2?
Description
Sets or queries Source B of the logic operation.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<src>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D1
1|D12|D13|D14|D15|CHANnel1|CHANnel2|C
HANnel3|CHANnel4}
CHANnel1
Remarks
 The logic operations include A&&B, A||B, A^B, and !A.
 This command is only available for the logic operation that contains two sources.
It is used to set Source B.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:MATH1:LSOUrce2 D4 /*Sets Source B of the logic operation to D4.*/
:MATH1:LSOUrce2? /*The query returns D4.*/
:MATH<n>:SCALe
Syntax
:MATH<n>:SCALe <scale>
:MATH<n>:SCALe?
Description
Sets or queries the vertical scale of the operation results. The unit is related to the
currently selected operator and the unit selected by the source.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<scale>
Real
Refer to Remarks
——
Remarks
The setting range of vertical scale is related to the currently selected operator and the
scale of the source channel. For integration and differentiation operations, the actual
range of <scale> is also related to the current horizontal time base.
Return
Format
The query returns the vertical scale of the current operation results in scientific
notation.
Example
:MATH1:SCALe 0.2 /*Sets the vertical scale to 200 mV.*/
:MATH1:SCALe? /*The query returns 2.000000E-1.*/

Rigol DS7024 Specifications

General

Bandwidth	200 MHz
Channels	4
Sample Rate	2 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Display	10.1 inch
Vertical Resolution	8 bit
Trigger Types	Edge, Pulse, Video, Window
Serial Bus Triggering and Decoding	I2C, SPI, UART, CAN
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ
