:TRIGger:DURATion
Command List:
 :TRIGger:DURATion:SOURce
 :TRIGger:DURATion:TYPE
 :TRIGger:DURATion:WHEN
 :TRIGger:DURATion:TUPPer
 :TRIGger:DURATion:TLOWer
 :TRIGger:DURation:LEVel
:TRIGger:DURATion:SOURce
Syntax
:TRIGger:DURATion:SOURce <source>
:TRIGger:DURATion:SOURce?
Description
Sets or queries the trigger source of Duration trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D10|D
11|D12|D13|D14|D15|CHANnel1|CHANnel2|
CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:DURATion:SOURce CHANnel2 /*Sets the trigger source to CH2.*/
:TRIGger:DURATion:SOURce? /*The query returns CHAN2.*/
:TRIGger:DURATion:TYPE
Syntax
:TRIGger:DURation:TYPE
<pch1>[,<pch2>[,<pch3>[,<pch4>[,<pla0>[,<pla1>[,<pla2>[,<pla3>[,<pla4>[,<
pla5>[,<pla6>[,<pla7>[,<pla8>[,<pla9>[,<pla10>[,<pla11>[,<pla12>[,<pla13>[,
<pla14>[,<pla15>]]]]]]]]]]]]]]]]]]]]
:TRIGger:DURation:TYPE?
Description
Sets or queries the channel pattern of Duration trigger.
Parameter
Name
Type
Range
Default
<pch1>
Discrete
{H|L|X}
X
<pch2>
Discrete
{H|L|X}
X
<pch3>
Discrete
{H|L|X}
X
<pch4>
Discrete
{H|L|X}
X
<pla0>
Discrete
{H|L|X}
X
...
...
...
...
<pla15>
Discrete
{H|L|X}
X
Remarks
 The parameter "<pch1> to <pch4>" sets the patterns of the analog channels
"CH1 to CH4". The parameter "<pla0> to <pla15>" sets the patterns of the digital
