:TRIGger:SHOLd
Command List:
 :TRIGger:SHOLd:DSrc
 :TRIGger:SHOLd:CSRC
 :TRIGger:SHOLd:SLOPe
 :TRIGger:SHOLd:PATTern
 :TRIGger:SHOLd:TYPE
 :TRIGger:SHOLd:STIMe
 :TRIGger:SHOLd:HTIMe
 :TRIGger:SHOLd:DLEVel
 :TRIGger:SHOLd:CLEVel
:TRIGger:SHOLd:DSrc
Syntax
:TRIGger:SHOLd:DSRC <source>
:TRIGger:SHOLd:DSRC?
Description
Sets or queries the data source of Setup&Hold trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D
10|D11|D12|D13|D14|D15|CHANnel1|
CHANnel2|CHANnel3|CHANnel4}
CHANnel2
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13,
D14, D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:SHOLd:DSRC CHANnel1 /*Sets the data source to CH1.*/
:TRIGger:SHOLd:DSRC? /*The query returns CHAN1.*/
:TRIGger:SHOLd:CSRC
Syntax
:TRIGger:SHOLd:CSRC <source>
:TRIGger:SHOLd:CSRC?
Description
Sets or queries the clock source of Setup&Hold trigger.
Parameter
Name
Type
Range
Default
<source>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|D9|D
10|D11|D12|D13|D14|D15|CHANnel1|
CHANnel2|CHANnel3|CHANnel4}
CHANnel1
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:TRIGger:SHOLd:CSRC CHANnel2 /*Sets the clock source to CH2.*/
:TRIGger:SHOLd:CSRC? /*The query returns CHAN2.*/
