Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-153
TLEVel: the trigger level adjustment knob.
WVOLt: the vertical scale adjustment knob for the waveform.
WPOSition: the vertical position adjustment knob for the waveform.
 The parameter <val> defines the specified rotation times of the knob. By default,
it is 1.
Example
:SYSTem:KEY:INCRease VOFFset2 /*Rotates the vertical offset adjustment knob of
CH2 clockwise.*/
:SYSTem:LANGuage
Syntax
:SYSTem:LANGuage <language>
:SYSTem:LANGuage?
Description
Sets or queries the system language.
Parameter
Name
Type
Range
Default
<language>
Discrete
{SCHinese|TCHinese|KORean|JAPanese|EN
GLish|GERMan|PORTuguese|POLish|FRENch
|RUSSian|SPAN}
SCHinese
Remarks
The language settings are not affected by factory default settings (send the *RST
command).
Return
Format
The query returns SCH, TCH, KOR, JAP, ENGL, GERM, PORT, POL, FREN, RUSS, or
SPAN.
Example
:SYSTem:LANGuage ENGLish /*Sets the system language to ENGLish.*/
:SYSTem:LANGuage? /*The query returns ENGL.*/
:SYSTem:PON
Syntax
:SYSTem:PON <power on>
:SYSTem:PON?
Description
Sets or queries the configuration type recalled by the oscilloscope when it is powered on
again after power-off.
Parameter
Name
Type
Range
Default
< power on >
Discrete
{LATest|DEFault}
DEFault
Return
Format
The query returns LAT or DEF.
Example
:SYSTem:PON LATest /*Sets the oscilloscope to recall Last value after it is powered on
again.*/
:SYSTem:PON? /*The query returns LAT.*/
