Chapter 2 Command System RIGOL
MSO7000/DS7000 Programming Guide 2-9
:BUS<n>:EVENt:FORMat
Syntax
:BUS<n>:EVENt:FORMat <format>
:BUS<n>:EVENt:FORMat?
Description
Sets or queries the display format of the specified decoding bus event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<format>
Discrete
{HEX|ASCii|DEC|BIN}
ASCii
Remarks
HEX indicates Hexadecimal; DEC indicates Decimal; BIN indicates Binary.
Return
Format
The query returns HEX, ASC, DEC, or BIN.
Example
:BUS1:EVENt:FORMat HEX
/*Sets the display format of the specified decoding bus event table to HEX.*/
:BUS1:EVENt:FORMat? /*The query returns HEX.*/
:BUS<n>:EVENt:VIEW
Syntax
:BUS<n>:EVENt:VIEW <packet>
:BUS<n>:EVENt:VIEW?
Description
Sets or queries the data page of the specified decoding bus event table.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2|3|4}
——
<packet>
Discrete
{PACKets|DETails|PAYLoad}
PACKets
Remarks
 PACKets: displays time, data, and error information in the specified event table.
 DETails: displays the detailed data of the specified row in the event table.
 PAYLoad: displays all the data of the specified column in the event table.
 When different views are selected, the export format of the data list will be
changed accordingly.
Return
Format
The query returns PACK, DET, or PAYL.
Example
:BUS1:EVENt:VIEW DETails /*Sets the data page of the decoding bus event table
to DETails.*/
:BUS1:EVENt:VIEW? /*The query returns DET.*/
:BUS<n>:LABel
Syntax
:BUS<n>:LABel <bool>
:BUS<n>:LABel?
Description
Enables or disables the label of the specified decoding bus; or queries the on/off status
of the label of the specified decoding bus.

Rigol DS7024 Specifications

General

Bandwidth	200 MHz
Channels	4
Sample Rate	2 GSa/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	1 ns/div to 1000 s/div
Input Coupling	AC, DC, GND
Operating Temperature	0 °C to +50 °C
Display	10.1 inch
Vertical Resolution	8 bit
Trigger Types	Edge, Pulse, Video, Window
Serial Bus Triggering and Decoding	I2C, SPI, UART, CAN
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ
