Rockwell Automation Publication 2198-RM006A-EN-P - December 2020 57
Appendix C
Specifications
Power Specifications This section provides the power specifications for the Ultra™ 3000 and
Kinetix® 5300 servo drives.
Ultra3000 (230V) Servo Drive Power Specifications
The table lists power specifications and requirements for the Ultra3000 230V
drives (2098-DSD-005x-xx, -010x-xx, and -020x-xx).
Attribute 2098-DSD-005 2098-DSD-010 2098-DSD-020
AC input voltage
(1)
100…240V rms, single-phase
AC input frequency 47…63 Hz
AC input current
(2) (3)
Nom (rms)
230V AC (0-pk) max inrush
(4)
5 A
100 A - Series A or B
20 A - Series C
9 A
100 A - Series A or B
20 A - Series C
18 A
100 A - Series A or B
20 A - Series C
Continuous output current (rms) 1.8 A 3.5 A 7.1 A
Continuous output current (0-pk) 2.5 A 5.0 A 10 A
Peak output current (rms) 5.3 A 10.6 A 21.2 A
Peak output current (0-pk) 7.5 A 15 A 30 A
Bus capacitance 1410 µF 1880 µF 1880 µF
Internal shunt resistance — — —
Shunt on ———
Shunt off ———
Bus overvoltage 400V DC 400V DC 400V DC
Energy absorption capability
115V AC input
230V AC input
93 J
38 J
125 J
51 J
Continuous power output
115V AC input
230V AC input
0.25 kW
0.5 kW
0.5 kW
1.0 kW
1.0 kW
2.0 kW
(1) Specification is for nominal voltage. The absolute limits are ±10%, or 88…265V rms.
(2) The 2098-DSD-005x-xx, 2098-DSD-010x-xx, and 2098-DSD-020x-xx (200V-class) drives are limited to:
Series A or B - one contactor cycle every 2 minutes.
Series C - one contactor cycle every 10 s for up to 2 minutes, not to exceed 12 cycles in 5 minutes.
(3) Power initialization requires a short period of inrush current. Dual element time delay (slow blow) fuses are recommended.
(4) Inrush current limiting circuitry is enabled within 3 s after removal of AC line power.
