Rockwell Automation Publication 2198-RM006A-EN-P - December 2020 65
Appendix C Specifications
Power Dissipation
Specifications
This section provides the power dissipation specifications for the Ultra3000
and Kinetix 5300 servo drives.
Ultra3000 Servo Drive Power Dissipation Specifications
Use the following table to size an enclosure and calculate required ventilation
for an Ultra3000 servo drive system. Typical heat losses run approximately
one-half maximum power losses. The maximum power losses are shown.
Kinetix 5300 Servo Drive Power Dissipation Specifications
Use this table to size an enclosure and calculate required ventilation for a
Kinetix 5300 drive system.
Ultra3000 Servo
Drive Cat. No.
Maximum Loss,
watts
Ultra3000 Servo
Drive Cat. No.
Maximum Loss,
watts
2098-DSD-005x-xx 48 2098-DSD-HV030x-xx 175 + dissipative shunt
2098-DSD-010x-xx 48 2098-DSD-HV050x-xx 175 + dissipative shunt
2098-DSD-020x-xx 50 2098-DSD-HV100x-xx 350 + dissipative shunt
2098-DSD-030x-xx 150 + dissipative shunt 2098-DSD-HV150x-xx 350 + dissipative shunt
2098-DSD-075x-xx 300 + dissipative shunt 2098-DSD-HV220x-xx 600 + dissipative shunt
2098-DSD-150x-xx 500 + dissipative shunt
Kinetix 5300 Drive
Cat. No.
AC Input,
nom
Usage as a % of Rated Power Output
(1)
(watts)
(1) Internal shunt power is not included in the calculations and must be added based on utilization.
20% 40% 60% 80% 100%
2198-C1004-ERS
200…230V
three-phase
12 16 20 25 29
2198-C1007-ERS 14 19 24 30 37
2198-C1015-ERS 26 36 47 59 71
2198-C1020-ERS 35 52 71 91 112
2198-C2030-ERS 53 87 124 164 206
2198-C2055-ERS 87 139 193 250 308
2198-C2075-ERS 97 159 225 293 364
2198-C4004-ERS
380…480V
three-phase
16 21 26 31 36
2198-C4007-ERS 20 30 39 48 58
2198-C4015-ERS 33 48 62 78 93
2198-C4020-ERS 39 58 79 101 124
2198-C4030-ERS 57 89 123 157 193
2198-C4055-ERS 112 171 231 293 356
2198-C4075-ERS 134 204 273 344 417
2198-C1004-ERS
200…230V
single-phase
12 16 20 25 30
2198-C1007-ERS 14 19 24 30 37
2198-C1015-ERS 25 36 47 59 72
2198-C1020-ERS 35 52 72 92 115
2198-C1004-ERS
110…120V
single-phase
11 14 18 22 26
2198-C1007-ERS 12 17 21 27 32
2198-C1015-ERS 23 32 42 53 64
2198-C1020-ERS 30 44 59 77 96
