64 Rockwell Automation Publication 2198-RM006A-EN-P - December 2020
Appendix C Specifications
Table 48 - Ultra3000 Drives 5V Supply Specifications
Table 49 - Ultra3000 Drive Auxiliary Power Specification (230V)
Table 50 - Ultra3000 Drive Auxiliary Power Specification (460V)
Kinetix 5300 Servo Drive Control Power Specifications
Table 51 - Control Power Current Specifications
Parameter Description Min Max
Voltage Voltage tolerance of the external logic supply. 5.1V 5.25V
Current
Current output capability of the external +5V DC power
supply.
1.5 A —
IMPORTANT
Using the drive-mounted breakout board with 24V to 5V auxiliary power
converter is preferred to using an external +5V DC power supply.
Specification 2098-DSD-030 2098-DSD-075 2098-DSD-150
Auxiliary AC input current
115V AC (rms) nom
230V AC (rms) nom
115V AC (0-pk) max inrush
230V AC (0-pk) max inrush
1.0 A
0.5 A
47 A
95 A
Attribute
2098-DSD-
HV030
2098-DSD-
HV050
2098-DSD-
HV100
2098-DSD-
HV150
2098-DSD-
HV220
Auxiliary AC input current
230V AC (rms) nom
360V AC (rms) nom
480V AC (rms) nom
230V AC (0-pk) max inrush
480V AC (0-pk) max inrush
0.55 A
0.35 A
0.25 A
47 A
68 A
Kinetix 5300 Drive
Cat. No.
24V Current per
Module
(non-brake motor)
A
DC
24V Current
(2 A brake motor)
(1)
A
DC
(1) See Kinetix Rotary Motion Specifications Technical Data, publication KNX-TD001, for brake current specifications of Kinetix
MP, TLP, and TL/TLY rotary motors.
24V Inrush Current
(2)
A
(2) Inrush current duration is less than 30 ms.
2198-C1004-ERS
0.4 2.4 1.8
2198-C1007-ERS
2198-C4004-ERS
2198-C4007-ERS
2198-C1015-ERS
0.9 2.9 2.4
2198-C1020-ERS
2198-C2030-ERS
2198-C4015-ERS
2198-C4020-ERS
2198-C4030-ERS
2198-C2055-ERS
1.7 3.7 3.0
2198-C2075-ERS
2198-C4055-ERS
2198-C4075-ERS
