Installing Power Wiring 5-7
Circuit Breakers
The “other devices” listings in table 5.4 include both circuit breakers
(inverse time or instantaneous trip) and self-protecting motor
starters. If one of these is chosen as the desired protection
method, the following requirements apply.
• IEC and UL – Both types of devices are acceptable for IEC and
UL installations.
Note: For carrier frequencies above 4 kHz, see figure 9.9.
Table 5.4 – Drive, Fuse, and Circuit Breaker Ratings
Drive Ratings
Model Number
Output Ratings Input Ratings
Branch Circuit
Protection
Power
Dissipation
kW (HP) Amps
Voltage
Range kVA Amps
Fuse
Rating
Other
Devices
IP20 Open
Watts
100 - 115V AC 1-Phase Input
; 0 - 230 V, 3-Phase Output
6MDVN-1P5101 0.2 (0.25) 1.5 90-126 0.75 6.0 10 10 25
6MDVN-2P3101 0.37 (0.5) 2.3 90-126 1.15 9.0 15 15 30
6MDVN-4P5101 0.75 (1.0) 4.5 90-126 2.25 18.0 30 30 50
6MDVN-6P0101 1.1 (1.5) 6.0 90-126 3.0 24.0 40 40 70
200 - 240V AC 1-Phase Input; 0 - 230 V, 3-Phase Output
6MDAN-1P5111 0.2 (0.25) 1.5 180-265 0.75 5.0 10 5 25
6MDAN-2P3111 0.37 (0.5) 2.3 180-265 1.15 6.0 10 10 30
6MDAN-4P5111 0.75 (1.0) 4.5 180-265 2.25 10.0 15 15 50
6MDAN-8P0111 1.5 (2.0) 8.0 180-265 4.0 18.0 30 25 80
200 - 240V AC 3-Phase Input; 0 - 230 V, 3-Phase Output
6MDBN-1P5101 0.2 (0.25) 1.5 180-265 0.75 1.8 3 5 25
6MDBN-2P3101 0.37 (0.5) 2.3 180-265 1.15 2.5 6 5 30
6MDBN-4P5101 0.75 (1.0) 4.5 180-265 2.25 5.2 10 7 50
6MDBN-8P0101 1.5 (2.0) 8.0 180-265 4.0 9.5 15 15 80
6MDBN-012101 2.2 (3.0) 12.0 180-265 5.5 15.5 25 25 115
6MDBN-017101 3.7 (5.0) 17.5 180-265 8.6 21.0 35 30 165
380 - 480V AC 3-Phase Input; 0 - 480 V, 3-Phase Output
6MDDN-1P4101 0.37 (0.5) 1.4 340-528 1.4 1.8 3 3 30
6MDDN-2P3101 0.75 (1.0) 2.3 340-528 2.3 3.2 6 4 40
6MDDN-4P0101 1.5 (2.0) 4.0 340-528 4.0 5.7 10 7 60
6MDDN-6P0101 2.2 (3.0) 6.0 340-528 5.9 7.5 15 10 90
6MDDN-8P7101 3.7 (5.0) 8.7 340-528 8.6 9.0 15 15 145
