9-28 MD60 AC Drive User Manual
The present DC bus voltage level.
The present operating status of the drive.
A code that represents a drive fault. The codes will appear in these
parameters in the order they occur (that is, Fault 1 Code in d007 will
contain the more recent fault). Repetitive faults will be recorded only
once. Refer to chapter 10 for the fault code descriptions.
d005 DC Bus Voltage
Range: Based on Drive Rating
Default: Read Only
See also: N/A
d006 Drive Status
Range: 0 = Condition False
1 = Condition True
See figure 9.10
Default: Read Only
See also: A095
Figure 9.10 – Drive Status (d006) Bit Definitions
d007
d008
d009
Fault 1 Code
Fault 2 Code
Fault 3 Code
Range: F2 to F122
Default: Read Only
See also: N/A
Running Digit 0
Forward Digit 1
Accelerating Digit 2
Decelerating Digit 3
