Technical Specifications A-1
APPENDIX A
Technical Specifications
Environment
Altitude: 1000 m (3300 ft) maximum without derating
Ambient Operating
Temperature
Without Derating:
IP 20: -10° C (14° F) to 50° C (122° F)
NEMA 1/IP30: -10° C (14° F) to 40° C (104° F)
Storage
Temperature (all
const.):
-40° C (-40° F) to 85° C (185° F)
Relative Humidity: 0% to 95%, non-condensing
Shock (Operating): 15 G peak for 11 ms duration (+/-1.0 ms)
Vibration
(Operating):
1 G peak, 5 to 2000 Hz
Control
Carrier Frequency: 2-16 kHz. Drive rating based on 4 kHz.
Frequency Accuracy • Digital Input: Within +/-0.05% of set output
frequency.
• Analog Input: Within 0.5% of maximum output
frequency.
Speed Regulation -
Open Loop with Slip
Compensation:
+/-2% of base speed across a 40:1 speed range.
Stop Modes: Multiple programmable stop modes including: Ramp,
Coast, DC-Brake, Ramp-to-Hold, and S Curve.
Accel/Decel: Two independently programmable accel and decel
times. Each time may be programmed from 0-600
seconds in 0.1 second increments.
Intermittent
Overload
• 150% Overload capability for up to 1 minute.
• 200% Overload capacity for up to 3 seconds
Electronic Motor
Overload Protection:
Class 10 protection with speed-sensitive response.
