PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-52 Programming and Parameters
UTILITY
Diagnostics
1402 [Last Stop Source]
Displays the source that initiated the most recent stop sequence.
Default:
Options: 0 =
1 - 5 =
6 =
7 =
8 =
9 =
10 =
11 =
12 =
13 =
Read Only
“Pwr Removed”
“DPI Port 1-5”
“Reserved”
“Digital In”
“Fault”
“Not Enabled”
“Reserved”
“Jog”
“Selftune”
“Reserved”
1403 [Start Inhibits]
Displays the inputs currently preventing the drive from starting. For each bit, 1=Inhibit condition true and 0=Inhibit condition
false.
Faults
263 [Clear Fault Que]
Allows you to clear the fault queue. Refer to Chapter 4
Troubleshooting on page 4-1
for information on clearing the fault
queue.
Default:
Options:
0 =
0 =
1 =
“Ready”
“Ready”
“Clr Flt Que”
1347 [Fault Clear]
Allows you to reset drive faults and/or clear the fault queue.
Default:
Options:
0 =
0 =
1 =
2 =
“Ready”
“Ready”
“Clear Faults”
“Clr Flt Que”
1348 [Fault Clr Mode]
Enables/Disables a fault reset (clear faults) attempt from any source.
This does not apply to fault codes which are cleared indirectly via
other actions.
Default:
Options:
1 =
0 =
1 =
“Enabled”
“Disabled”
“Enabled”
1349 [Status1 at Fault]
Captures and displays Par 381 [Drive Status 1] bit pattern at the time of the last fault. 0=Condition False, 1=Condition True.
381
1350 [Status2 at Fault]
Captures and displays Par 382 [Drive Status 2] bit pattern at the time of the last fault. 0=Condition False, 1=Condition True.
382
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Reserved Reserved DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Digital In Reserved Startup Actv Reserved Stop Assertd Reserved Enable Type 2 Alarm Fault
Default
xxx00000x001x000
Bit
1514131211109876543210
Spd Ref ID 3 Spd Ref ID 2 Spd Ref ID 1 Spd Ref ID 0 Local ID 2 Local ID 1 Local ID 0 At Speed Faulted Alarm Decelerating Accelerating Actual Dir Command Dir Active Ready
Default
0000111010001100
Bit
1514131211109876543210
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Auto Tuning Curr Limit Stopping Jogging Running Active Ready
Default
xxxxxxxxx0001100
Bit
1514131211109876543210
