41
8 About the Blades and Materials
Rubber Sandblast Stencils
Use rubber sandblast stencils that meet the conditions shown in the
figure at right.
A) Materials with a material thickness of 1 mm (0.04 in.) or
less
B) Materials with only carrier paper on both flanks of the
material
Position the left and right pinch rollers above the strips of carrier
paper.)
C) Materials with carrier paper which is hard enough to
withstand material feed
A material with edge holes for sprocket feed
Material for sprocket-feed use has feed holes along both edges.
If the material is loaded with these holes lying over the pinch
rollers, material feed cannot be performed correctly.
Do not put the pinch rollers on the hole area at the edges.
Carrier paper
B) 15 mm (9/16 in.) or more B) 15 mm (9/16 in.) or more
Material A) 1 mm (0.04 in.)
or less
