Roland Camm-1 CX-24/12 User Manual

52
11 What to do if...
11-5 Error Messages
The location of one or more of the pinch rollers is not correct.
Press the [ENTER] key to clear the error.
Position the pinch rollers appropriately over the grit rollers and
reload the material.
Refer to "4-2 Loading the Material."
When the machine was put into the setup state, no material
was loaded.
The material was removed when the machine was in the setup state.
The material came loose during cutting.
Load the material, then put the machine in the setup state.
Press the [ENTER] key to clear the error.
Refer to "4-2 Loading the Material."
When [REPLOT] was executed, the amount of data sent from
the computer exceeded the buffer size of the CX-24/12.
Reduce the amount of data, then execute [REPLOT].
Refer to "7 Repeating the same cutting."
[REPLOT] was executed when there was no data in the
buffer.
Send the data from the computer, then execute [REPLOT].
Refer to "7 Repeating the same cutting."
The following error messages are displayed for informational purposes when the data described in "Details" is sent. When one of these
error messages appears on the display, sending of data stops and you are not allowed to perform the next operation.
Press the [ENTER] key to clear the error from the display.
Note that even after you clear the error message, the CX-24/12 retains in memory the fact that the error occurred, and so correct cutting
may not be possible even if data continues to be sent. To cancel the error, switch the power off and back on.
Meaning
Appears if an instruction that the CX-24/12 cannot interpret is sent.
Meaning
Appears if the number of parameters differs from the permissible
number.
Meaning
Appears if the value specified for a parameter is out of the permis-
sible range.
Err:Bad Positin
SHEET UNLOADED
DATA OVERFLOW
DATA EMPTY
Er1:Wrong CMD.
Er2:Wrong No.s
Er3:Out of Range
