43
9 Display Menu Descriptions
Stored in Memory
Factry Default
Setting Range
Steps
Description
FORCE | < 50g>
Stored in Memory
Factry Default
Setting Range
Steps
Description
Yes
50 g
30 to 200 g
10 g
This sets the blade force used when cutting material.
Perform a cutting test and set the conditions to match the loaded material and
the installed cutter.
FORCE
SPEED
SPEED |<40cm/s>
Yes
40 cm/s
1 to 40 cm/s
1 cm/s when in the range of 1 to 10 cm/s
5 cm/s when in the range of 10 to 40 cm/s
This sets the speed used when cutting material.
Set this to a suitable value for the loaded material and installed blade.
Stored in Memory
Factry Default
Selection Choices
Description
Yes
0.250 mm
0 mm (PEN), 0.175 mm, 0.250 mm, 0.500 mm
This sets the amount of offset for the tip of the blade.
Set a value that matches the conditions for the blade installed.
When using the included test material and blade or equivalent parts, cutting
can be performed using the factory-default settings.
OFFSET| <0.250>
OFFSET
Stored in Memory
Factry Default
Selection Choices
Description
Yes
1.0 m
-24.9 to 24.9 m
This ensures that the material will not come loose during cutting by feeding
out the length of material to be cut before actually performing cutting.
When performing continuous cutting on the same material, this can also be
used to make sure that there is enough remaining material to cut the data that
will be sent.
AREA |< 1.0m>
AREA
To Next Page
