Roland V-4EX User Manual

3
WARNING
001-60
To completely turn o power to the unit, pull out
the plug from the outlet
• Even with the power switch turned o, this unit is not
completely separated from its main source of power. When
the power needs to be completely turned o, turn o the
power switch on the unit, then pull out the plug from the
outlet. For this reason, the outlet into which you choose to
connect the power cord’s plug should be one that is within
easy reach and readily accessible.
001-70
Concerning the AUTO OFF function
• The power to this unit will be turned o automatically
after a predetermined amount of time has passed
since its buttons or controls were last operated (AUTO
OFF function).
If you do not want the power to be turned o
automatically, disengage the AUTO OFF function (p. 10).
002d
Do not disassemble or modify by yourself
• Do not open or perform any internal modications on the
unit or its AC adaptor. (The only exception would be where
this manual provides specic instructions which should be
followed in order to put in place the video fader; see p. 57.)
003
Do not repair or replace parts by yourself
• Do not attempt to repair the unit, or replace parts within
it (except when this manual provides specic instructions
directing you to do so). Refer all servicing to your retailer,
the nearest Roland Service Center, or an authorized Roland
distributor, as listed on the “Information” sheet.
004
Do not use or store in the following types of
locations
• Subject to temperature extremes (e.g., direct sunlight in
an enclosed vehicle, near a heating duct, on top of heat-
generating equipment); or are
• Damp (e.g., baths, washrooms, on wet oors); or are
• Exposed to steam or smoke; or are
• Subject to salt exposure; or are
• Humid; or are
• Exposed to rain; or are
• Dusty or sandy; or are
• Subject to high levels of vibration and shakiness.
WARNING
007
Do not place in an unstable location
• Make sure you always have the unit placed so it is level and
sure to remain stable. Never place it on stands that could
wobble, or on inclined surfaces.
008c
Use only the supplied AC adaptor and the correct
voltage
• Be sure to use only the AC adaptor supplied with the unit.
Also, make sure the line voltage at the installation matches
the input voltage specied on the AC adaptor’s body. Other
AC adaptors may use a dierent polarity, or be designed
for a dierent voltage, so their use could result in damage,
malfunction, or electric shock.
008e
Use only the supplied power cord
• Use only the attached power-supply cord. Also, the supplied
power cord must not be used with any other device.
009
Do not bend the power cord or place heavy
objects on it
• Do not excessively twist or bend the power cord, nor
place heavy objects on it. Doing so can damage the cord,
producing severed elements and short circuits. Damaged
cords are re and shock hazards!
011
Don’t allow foreign objects or liquids to enter
unit; never place containers with liquid on unit
• Do not place containers containing liquid (e.g., ower vases)
on this product. Never allow foreign objects (e.g., ammable
objects, coins, wires) or liquids (e.g., water or juice) to enter
this product. Doing so may cause short circuits, faulty
operation, or other malfunctions.
USING THE UNIT SAFELY

Roland V-4EX Specifications

General

On/off switch	Yes
Product color	Black
Rack mounting	No
Output current	2 A
Power source type	AC
Video resolutions	640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 1200, 1920 x 1200 pixels
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL
BNC input ports	4
Number of HDMI outputs	2
VGA (D-Sub) input ports	1
Display type	LCD
Display resolution	320 x 240 pixels

Weight and Dimensions

Depth	296 mm
Width	225 mm
Height	105 mm
Weight	2600 g
