Roland V-4EX User Manual

44
Main Specications
Signal Processing
Video 4:2:2 (Y/Pb/Pr), 8 bits (Internal Processing : 480/59.94p when set to NTSC, 576/50p when set to PAL)
Audio Sampling Rate : 24 bits/48 kHz, 2 ch
Input/Output Formats
Refer to “About Input/Output Formats” (p. 23).
Input/Output Connectors
Input
Video
HDMI Type A (19 pins) x 4 (INPUT 1 -- 4)
RGB/Component
HD DB-15 type x 1 (INPUT 4)
Composite BNC Type x 4 (INPUT 1 -- 4)
S-Video 4-pin mini DIN type x 1 (INPUT 4)
Audio RCA pin type x 1 pair (AUDIO IN)
Output
Final Output
HDMI Type A (19 pins) x 1 (OUTPUT)
RGB/Component HD DB-15 type x 1 (OUTPUT)
Composite BNC type x 1 (OUTPUT)
Preview Output HDMI Type A (19 pins) x 1 (PVW OUT)
Other Connectors
MIDI 5 pins DIN type x 2 (IN, OUT/THRU)
USB B type x 1 (for streaming and remote control)
Signal Level/Impedance
RGB/Component
Signal Level 1.0 Vp-p (luminance), 0.7 Vp-p (chroma)
Impedance 75 ohms
Composite
Signal Level 1.0 Vp-p
Impedance 75 ohms
S-Video
Signal Level 1.0 Vp-p
Impedance 75 ohms
Analog Audio
Nominal Input Level - 10 dBu
Maximum Input Level + 8 dBu
Impedance 15 k ohms
Video Eects
Transition Mix, Cut, Wipe (259 patterns)
Composition/Filter Picture in Picture, Luminance Key, Chroma Key, Strobe, Negative, Colorize, Feedback, Emboss, Multi, Mirror etc. (148 types)
Others Output Fade, Freeze
Others
Display Graphic Color LCD, 320 x 240 dots, touch panel
Power Supply AC adaptor (DC 9 V)
Current Draw 2.0 A
Dimensions
225 (W) x 296 (D) x 105 (H) mm
8-7/8 (W) x 11-11/16 (D) x 4-3/16 (H) inches
Weight
(excl. AC adaptor)
2.6 kg
5 lbs 12 oz
Accessories AC adaptor, Power Cord, RCA - BNC conversion plug x 2, Owner’s Manual
* 0 dBu = 0.775 Vrms
* In the interest of product improvement, the specications and/or appearance of this unit are subject to change without prior notice.
Appendices

Roland V-4EX Specifications

General

On/off switch	Yes
Product color	Black
Rack mounting	No
Output current	2 A
Power source type	AC
Video resolutions	640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1366 x 768, 1400 x 1050, 1600 x 1200, 1920 x 1200 pixels
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL
BNC input ports	4
Number of HDMI outputs	2
VGA (D-Sub) input ports	1
Display type	LCD
Display resolution	320 x 240 pixels

Weight and Dimensions

Depth	296 mm
Width	225 mm
Height	105 mm
Weight	2600 g
