1-3. Other Component Specifi cations
Outdoor Units SPW-C256VH
MODEL No.
Outdoor Unit SPW-C256VH
Power Transformer
–
Rated –
Source VAC, Hz –
Secondary
–
–
Coil resistance
Ω
–
Thermal cut off temperature °C –
Thermistor (Coil / Air sensor): TH1, TH2, TH3, TH4
PB2M-41E-S1, DTN-C532G3H
Resistance
kΩ
–10°C: 24.6±5% 20°C: 6.5±5%
–5°C: 19.3±5% 30°C: 4.4±5%
0°C: 15.0±5% 40°C: 3.1±5%
5°C: 12.1±5% 45°C: 2.6±5%
10°C: 9.7±5% 50°C: 2.1±5%
Thermistor (Discharge gas sensor): TH5
CM-12
Resistance
kΩ
60°C: 12.4±5% 90°C: 4.6±5%
70°C: 8.7±5% 100°C: 3.4±7%
75°C: 7.4±5% 110°C: 2.5±7%
80°C: 6.3±5% 120°C: 1.9±7%
85°C: 5.3±5% 130°C: 1.5±7%
Relay (Comp. Magnetic Contactor)
Coil rated VAC –
Contact rating VAC, A –
Coil resistance (at 20°C)
Ω
–
Sol-Control-Valve
Sol-control-valve UKV-18D13
Magnetic coil UKV-A052, DC12V
4 way valve
4 way valve SHF-7H-34U
Elec magnetic coil SQ653, AC 220-240 V, 50/60Hz
