Item
code
Item
Setting data
No. Description No. Description No. Description
Type
0000
1-Way Air Discharge
Semi-Concealed (A)
0001
4-Way Air Discharge
Semi-Concealed
(X, XM)
0002
2-Way Air Discharge
Semi-Concealed (S)
0003
1-Way Air Discharge
Semi-Concealed Slim (L)
0005
Concealed-Duct
(U, US)
0006
Concealed-Duct High
Static Pressure (D)
0007 Ceiling-Mounted (T) 0008 Wall-mounted (K) 0010 Floor Standing (F)
0011
Concealed Floor
Standing (FM)
Indoor unit
capacity
0001 22 (Type 7) 0003 28 (Type 9) 0005 36 (Type 12)
0007 45 (Type 16) 0009 56 (Type 18) 0011
71 (Type 25)
For FR25 and
FMR25
0012
80 (Type 25)
(Except FR25, FMR25)
0015 112 (Type 36) 0017 140 (Type 48)
0018 160 (Type 60) 0021 224 (Type 70) 0023 280 (Type 96)
System
address
0001 Unit No. 1
0002 Unit No. 2
0003 Unit No. 3
0030 Unit No. 30
0099 Not set
Indoor unit
address
0001 Unit No. 1
0002 Unit No. 2
0003 Unit No. 3
0064 Unit No. 64
0099 Not set
Group control
address
0000 Individual (1:1 = Indoor unit with no group wiring)
0001 Main unit (One of the group-control indoor units)
0002 Sub unit (All group-control indoor units except for main unit)
0099 Not set
Cooling intake
temperature
shift
–010
Shifts intake temperature by
–
10°C.
–009
Shifts intake temperature by
–
9°C.
–001
Shifts intake temperature by
–
1°C.
0000 No intake temperature shift
0001 Shifts intake temperature by +1°C.
0009 Shifts intake temperature by +9°C.
0010 Shifts intake temperature by +10°C.
Automatic
stop time after
operation start
0000 Function disabled
0001 Stops automatically 5 minutes after operation starts.
0002 Stops automatically 10 minutes after operation starts.
Can be set
in 5-minute
units.
*
0123 Stops automatically 615 minutes after operation starts.
0124 Stops automatically 620 minutes after operation starts.
0125 Stops automatically 625 minutes after operation starts.
7-4. List of Detailed Setting Items
