Sanyo SPW-C366VH8 User Manual

1
1-288
Air intake
Air intake
ø18 Drain port
ø19 Drain port
Air discharge
Anchor bolt hole
(Anchor bolt M8)
Refrigerant tubing joint (gas tube)
Flare connection ø15.88 mm
Refrigerant tubing joint (liquid tube)
Flare connection ø9.52 mm
Unit: mm
1-4. Dimensional Data
(B) Outdoor Unit: SPW-C256VH
4-o12
790 70
569
15
12
50 50
249 320
100
(97)
46
(13)
(23.5)27.5
13
50
50
12
46
85608
285
336 310
(157)153
(161)
51
149
25
110
109
(B) Outdoor Unit: SPW-C256VH8, C366VH8
940
339
366
3
2
780
4
4
4
4
5
5
5
5
1
50
50
170 110
340
15 10380
405
660
27
1
2
3
4
5
Unit: mm
Hole for anchor bolt (4–R6.5) / Anchor bolt: M10
Refrigerant tube joint (liquid line tube) Flare connection 3/8 in (ø9.52 mm)
Refrigerant tube joint (gas line tube) Flare connection 5/8 in (ø15.88 mm)
Refrigerant tube inlet (knock-out hole)
Power supply inlet (knock-out hole ø38, ø29, ø19, ø16 mm)
SM830160-03ClassicPAC-iA4.ind288288SM830160-03ClassicPAC-iA4.ind288288 2010/02/1610:26:412010/02/1610:26:41
