1-4. Dimensional Data
(A) Indoor Unit: Concealed-Duct Type
12, 16, 18 Types
SPW-UR124GH56 (A/B), U125H, U125HN
SPW-UR164GH56 (A/B), U165H, U165HN
SPW-UR184GH56 (A/B), U185H, U185HN
Refrigerant liquid line ø6.35 (liquid tube)
Refrigerant gas line ø12.7
Upper drain port (O.D. 32 mm)
Bottom drain port (O.D. 32 mm)
Suspension lug
Power supply outlet (2-ø30)
Fresh air intake port (ø150)
Flange for the  exible air outlet duct (ø200)
Tube cover
Electrical component box
Flange for the air intake duct
(Option or  eld supply)
Inspection access
(450 × 450)
(Field supply)
(Hole)
(Suspension bolt pitch)
(Suspension bolt pitch)
(Air outlet
duct  ange)
662 (Air outlet duct  ange)
Unit : mm
