Description
Page 3-4 BASO 1 MS - 02.03 - V02
3.1.6 Serial plate
The serial plate contains the machine-specific data. This se-
rial plate is on the inside of the machine and is visible when
the coffee ground container is removed
3.2
Product data
3.2.1 Performance
The output is 80 to 120 cups of coffee or tea per day.
3.2.2 Dimensions
Width 420 mm
Height 620 mm
Depth 510 mm
Outlet height coffee 95 / 170 mm
Weight 33 kg (1 SO)
Subject to modification!
3.2.3 Energieversorgung
Model Connecting values
1 SO 2.2 kW / 10 A 230 V AC (PNE)
1 SO Tee 2.2 kW / 10 A 230 V AC (PNE)
1 SO Tee-Simultan 2.2 kW / 10 A 230 V AC (PNE)
15 SO 2.2 kW / 10 A 230 V AC (PNE)
15 SO Power steam 6.0 kW / 16 A 400 V AC (3 PNE)
15 SO Power steam 5.3 kW / 25 A 210 V AC (PNE) USA
The electrical connection must be effected according to the existing prescriptions (VDE 0100) and
the local laws and prescriptions.
The power supply line must be at least H 07 RN-F. The voltage indicated on the machine type
plate must be identical with the one where the machine will be used.
The phase must be secured with 10A, with the exception of the 15 SO Powersteam.
For special voltages please contact M. Schaerer Ltd. or an authorized representative.
Inst. No: ..................................................
Type: ..................................................
Serial-No: ..................................................
Pressure: .................................................. bar
Voltage: .................................................. Watt
Power: .......................VAC.................... Hz
