Appendix
Page 7-4 BASO 1 MS - 02.07 - V02
7.3 Serial plate of steam generator and instant heater
Type
Type HW DA
Excess operating pressure ......... ............ ......... ....... 2,5 bar . ....... 2.5 bar
Maximum excess op. pressure p max ............ ......... ........ 12 bar . ........ 12 bar
Test excess pressure ......... ............ ......... ........ 24 bar . ........ 24 bar
Maximum op. temperature T max ............ ......... ...... 192 °C .. ...... 192 °C
Minimum op. temperature T min ............ ......... ........ 10 °C .. ........ 10 °C
Operating temperature
1
)....... ............ ......... ........ 95 °C .. ...... 130 °C
Water capacity Vol.... ............ ......... ....... 0,8 l...... ....... 0.8 l
Voltage
2
)U.... ............ ......... ...... 230 VAC ...... 230 VAC
Capacity (Watts)
3
)P .... ............ ......... .... 2000 W ... .... 2000 W
Construction year:....................................... ............... ......... 200................ 200.....................
Manufacture number................................... ......................... HW................ DA......................
....................................................................
1
) temperature selectable
2
) 230V or 115V
3
) 2000W or 1750W
7.4 Environmental aspects
Spare parts: Parts exchanged during a service are reconditioned as far as possible and used
again.
Cleaning agents: Environmental protection!
If no recycling is not possible, cleaning agents and their packaging must be disposed
of in line with local laws and regulations in accordance with the "HEALTH AND
SAFETY DATA SHEET."
Energy consumption:
The energy consumption corresponds to the technical state of the art at the time the
machine was developed.
Disposal: Environmental protection!
The machines must be disposed off correctly and in accordance with local laws and
regulations.
