BASCJ_EN
V03 | 07.2015
9
www.schaerer.comProduct description
Technical data
We reserve the right to make technical changes.
* For special equipment, see serial plate. The values specified here apply to the basic equip-
ment.
** The A-weighted noise level (slow) and Lpa (impulse) at the workplace of the operating per-
sonnel is below 70 dB (A) for every operating mode.
Water filter for internal drinking water tank The water filter can be installed in the internal
drinking water tank.
Capacity: 200 l
Mains water supply The tank is filled via a water inlet outside of
the machine. This option can be retrofitted.
For detailed information, please contact your sales partner.
Example Option Description
Nominal power* 1700 – 2300 W
Operating temperature Steam boiler Hot water boiler
Minimum operating temperature (T min.) 130°C 86°C
Maximum operating temperature (T max.) 130°C 102°C
Overpressure Steam boiler Hot water boiler
Working overpressure 2.5 bar 16 bar
Permissible working overpressure (p max) 16 bar 16 bar
Test overpressure 24 bar 24 bar
Water tank capacity 2.2 l
Bean hopper capacity 250 g
Increased bean hopper capacity (optional) 400 g
Grounds container capacity 20 coffee grounds cakes
External dimensions
Width 305 mm
Height 405 mm
Depth 445 mm
Empty weight 16 kg
Permanent noise level** <70 dB (A)
