160
Date/Time Setting
You can set the date and time for the register.
Procedure
1.
In the SETTING window, select “9 DATE/TIME”.
• The DATE/TIME window will appear.
2.
Set each item as follows:
• DATE (Use the numeric entry)
Enter the day (2 digits), month (2 digits), and year (2 digits)
in this sequence.
• TIME (Use the numeric entry)
Set the time (max. 4 digits) on the 24-hour system. For
example, when the time is set to 2:30 AM, enter 0230;
and when it is set to 2:30 PM, enter 1430. The time will be
printed and displayed.
