Sharp ER-A421 User Manual

217
■
Installing the paper rolls
<Receipt side>
1.
Remove the printer cover and open the print roller arm of the receipt
side by following the steps in “Removing the paper rolls”.
2.
Set a paper roll in the paper roll cradle of the receipt side as per the
diagram.
3.
Feed the end of the paper along with the paper positioning guides
as per the diagram.
4.
While holding down the paper, slowly close the print roller arm of the
receipt side, and push down the
mark on the arm until you
hear a click locking the arm.
NOTE
If the print roller arm is not securely locked, printing is
not done right. If this problem occurs, open the arm,
and close the arm as instructed above.
5.
Wait until the excess paper is automatically cut off, and remove it.
NOTE
Do not remove the excess paper until the receipt
cutter stops completely. Trying to remove the paper
before the cutter stops completely could cause paper
jamming.
<Journal side>
6.
Lift up the print roller arm of the journal side.
7.
Set a paper roll in the paper roll cradle of the journal side as per the
diagram.
Paper positioning guides
8.
While holding down the paper, slowly close the print roller arm of the
journal side, and push down the arm until you hear a click locking
the arm.
Spool
Paper holding plate
9.
Remove the paper holding plate from the spool.
Insert the end of the paper into the slit in the spool. (Press the
}
key to feed more paper if required.)
Wind the paper two or three turns around the spool shaft.

Sharp ER-A421 Specifications

General

Memory type	Flash ROM
Types of payment	Cash
Electronic journal	Yes
Compatible memory cards	SD
Keyboard number of keys	119
Number of clerks/departments	99
Number of programmable VAT rates	6
Number of Price Look-Up codes (PLUs)	20000 PLUs
Supported paper width	58 mm
Display digits	24 digits
Display number of lines	10 lines
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	424 mm
Width	355 mm
Height	305 mm
Weight	12000 g
