117/327
Building Technologies Basic Documentation LMV5... CC1P7550en
7 Boiler controller / load controller 22.05.2018
7.5 Actual values (X)
Measuring accuracy: Min. °1% of the measuring range (excluding the sensor error).
Definition of sensors (incl. activation / deactivation of the temperature limiter
function):
Pt100 Temperature sensor Pt100 at the input X60, internal temperature limiter
function = activated.
Pt1000 Temperature sensor Pt1000 at the input X60, internal temperature limiter
function = activated.
Ni1000 Temperature sensor LG-Ni1000 at the input X60, internal temperature
limiter function = activated.
TempSensor Temperature sensor at the input X61, internal temperature switch
function = deactivated.
PressSensor Pressure sensor at the input X61, internal temperature switch
function = deactivated.
Pt100Pt1000 Temperature sensor Pt100 at input X60 for temperature controller
and temperature limiter function and temperature sensor Pt1000 at
input X60 additionally for temperature limiter function.
Pt100Ni1000 Temperature sensor Pt100 at input X60 for temperature controller and
temperature limiter function and temperature sensor LG-Ni at input X60
additionally for temperature limiter function.
No Sensor No actual value sensor (e.g. in the case of external predefined loads
and without internal temperature limiter).
Parameter PhysicalUnits ( ↓C / bar / °F / psi)
SensorSelect (Pt100 / Pt1000 / Ni1000 / TempSensor / PressSensor /
Pt100Pt1000 / Pt100Ni1000 / No Sensor)
