Siemens LMV51.100C1 User Manual

267/327
Building Technologies Basic Documentation LMV5... CC1P7550en
19 O2 trim control with LMV52 and PLL52 22.05.2018
19.4.14 Displaying the O2 trim controller status
The status of the O2 trim controller can be read out with the AZL52 via data point State
O2 Ctrl.
deactivated The O2 trim controller is not active. The system operates along the
ratio control curves.
locked The manipulated variable of the O2 trim controller is held at the last
value.
LockTStart Locking time following startup until the O2 trim controller is initialized
or released. The locking time is necessary in order to ensure that the
actual O2 value is measured. The O2 trim controller is still
deactivated or locked
InitContr The O2 trim controller is initialized. The O2 trim controller is locked.
LockTLoad The O2 trim controller is locked due to a load change.
active The O2 trim controller is active and operates to the O2 setpoint.
LockTCAct If switching functions (control interventions by the O2 trim controller)
are active, the O2 trim controller is locked for 2 x Tau.
Process
data
display
values
State O2 Ctrl (deactivated / locked / LockTStart / InitContr / LockTLoad
/ active / LockTCAct)
