Building Technologies Basic Documentation LMV5... CC1P7550en
21 Dimensions 22.05.2018
21 Dimensions
Dimensions in mm
66
33
19 36
9
41,5 41,5
222
240
83
9 142
160
7550m03/0703
Figure 127: Dimension PLL52
PLL52
