176/327
Building Technologies Basic Documentation LMV5... CC1P7550en
9 Commissioning instructions for the LMV5 22.05.2018
9.3 Settings for multistage oil-fired operation
Fuel changeover on the AZL5 is possible only if input FuelSelect is set to internal.
Set fuel selection to Oil or set the external fuel selector to Oil.
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Operation
Fuel
FuelSelect
Here, the burner operation mode can be set to 2-stage or 3-stage.
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
RatioControl
OilSettings
CurveParams
Operation Mode
Activate the program stop if startup shall be interrupted to continue setting the special
positions.
Prepurge Phases 24…34
Ignition position Phase 36
Interval 1 Phase 44
Interval 2 Phase 52
Postpurge Phases 72…78
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Menu level 5 Menu level 6
Params & Display
RatioControl
ProgramStop
deactivated
24PrePurgP
32PreP FGR
36IgnitPos
44Interv1
52Interv2
72PostPPos
76PostPFGR
Activate a program stop in phase 24.
18. Fuel changeover
for oil-fired operation
19. Changing the burner
operation mode from
modulating to multistage
(only when firing on oil)
20. Activating the
program stops in the
different program phases
